Imaging

Lens Mount

Canon EF

Camera Format

Full-Frame (1.0x Crop Factor)

Pixels

Actual: 27.1 Megapixel

Effective: 26.2 Megapixel

Max Resolution

26 MP: 6240 x 4160

Aspect Ratio

1:1, 3:2, 4:3, 16:9

Sensor Type / Size

CMOS, 35.9 x 24 mm

File Formats

Still Images: JPEG, RAW

Movies: MJPEG, MOV, MP4, MPEG-4 AVC/H.264

Audio: AAC

Bit Depth

14-Bit

Dust Reduction System

Yes

Memory Card Type

SDXC

SDHC

SD

Image Stabilization

Digital, 5-Way

Focus Control

Focus Type

Auto & Manual

Focus Mode

Automatic (A), Continuous-Servo AF (C), Manual Focus (M), Single-servo AF (S)

Autofocus Points

Phase Detection: 45 (45 Cross-Type)

Viewfinder/Display

Viewfinder Type

Optical

Viewfinder Eye Point

21.00 mm

Viewfinder Coverage

0.98

Viewfinder Magnification

Approx. 0.71x

Diopter Adjustment

-3 to +1 m

Display Screen

3"  Swivel Touchscreen LCD (1,040,000)

Screen Coverage

1

Diagonal Angle of View

170.0°

Exposure Control

ISO Sensitivity

Auto, 100-40000 (Extended Mode: 50-102400)

Shutter

Type: Mechanical

Speed: 30 - 1/4000 Second , Bulb Mode

Remote Control

TC-80N3, RS-80N3 (Optional)

Mirror Lock-Up

Yes

Metering Method

Center-Weighted Average Metering, Evaluative Metering, Partial Metering, Spot Metering

Exposure Modes

Modes: Aperture Priority, Auto, Manual, Programmed Auto, Shutter Priority

Metering Range: EV 1.0 - EV 20.0

Compensation: -5 EV to +5 EV (in 1/3 or 1/2 EV Steps)

Continuous Shooting

Up to 6.5 fps at 26.2 MP

Up to 3 fps at 26.2 MP

White Balance Modes

Auto, Cloudy, Color Temperature, Custom, Daylight, Flash, Fluorescent (White), Shade, Tungsten

Flash

Built-in Flash

No

Max Sync Speed

Mechanical Shutter:1 / 180 Second

Flash Compensation

-3 EV to +3 EV (in 1/3 or 1/2 EV steps)

Dedicated Flash System

eTTL

External Flash Connection

Hot Shoe

AV Recording

Video Recording

Yes, NTSC

Video Format

1920 x 1080p at 23.98, 29.97, 59.94 fps

1280 x 720p at 29.97, 59.94 fps

Aspect Ratio

0.672916667

Frame Rate

@ 1920 x 1080: 60 fps, 30 fps, 24 fps

@ 1280 x 720: 60 fps, 30 fps

Exposure Control

Auto: Shutter Speed, Aperture, ISO

Manual: Shutter Speed, Aperture, ISO

ISO Sensitivity

Auto, 100 - 25600

Exposure Compensation

-3 EV to +3 EV (in 1/3 EV steps)

Focus

Auto

Manual

Continuous Auto

Max Video Clip Length

1920 x 1080: 29 Minutes, 59 Seconds

Audio Recording

Built-In Mic: With Video (Stereo)

Optional External Mic: With Video (Stereo)

Performance

Start-up Time

0.2 seconds

Shutter Lag

0.06 seconds

Self Timer

10 Seconds, 2 Seconds

Interval Recording

Yes

Connectivity

1/8" Microphone, Canon N3, HDMI C (Mini), Mini-USB, USB 2.0

Wi-Fi Capable

Yes

Power

Battery

1 x LP-E6N Rechargeable Lithium-Ion Battery Pack, 7.2 VDC, 1865 mAh

AC Power Adapter

AC-E6N with DR-E6 (Optional)

Operating/Storage Temperature

Operating

32 to 104°F (0 to 40°C)

Humidity: 0 - 85%

Physical

Dimensions (WxHxD)

5.7 x 4.4 x 2.9" / 144.0 x 110.5 x 74.8 mm

Weight

1.51 lb / 685 g body only

Kit Lens

Focal Length

24 - 105mm

Aperture

Maximum: f/3.5 - 5.6

Angle of View

84° - 23° 20'

Minimum Focus Distance

15.75" (40 cm)

Elements/Groups

17 / 13

Diaphragm Blades

7, Rounded

Autofocus

Yes

Image Stabilization

Yes

Filter Thread

Front: 77 mm

Dimensions (DxL)

Approx. 3.28 x 4.09" (83.4 x 104 mm)

Weight

1.16 lb (525 g)
