SPECIFICATION

• 8 PoE+ Ports: Provides eight 10/100 Mbps Fast Ethernet ports that support IEEE 802.3af/at Power over Ethernet (PoE) with up to 30W per port.
• 2 Uplink Ports: Two 10/100 Mbps Fast Ethernet ports for connecting to other network devices.
• Long Reach PoE: Supports extended PoE distances up to 250 meters.
• High Power Budget: Offers a total PoE budget of 96W.
• Auto-Negotiation: Automatically detects the optimal speed and duplex mode for each connected device.
• Auto MDI/MDIX: Eliminates the need for crossover cables.
• Plug-and-Play Installation: Easy setup with no configuration required.
• Metal Chassis: Provides enhanced durability and heat dissipation.
• Energy Efficient: Incorporates energy-saving features to reduce power consumption.
• Surge Protection: Built-in 6kV surge protection to protect the switch from electrical surges.

Technical Specifications:

• Ports:
  • 8 x 10/100 Mbps Fast Ethernet PoE+ Ports
  • 2 x 10/100 Mbps Uplink Ports
• Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3af/at
• Data Transfer Rates: 10 Mbps, 100 Mbps (Auto-Negotiation)
• Media: UTP Cat. 3, 4, 5, 5e
• Flow Control: Backpressure
• Dimensions: 184 x 94 x 27 mm (Approx.)
• Weight: 0.95 kg (Approx.)
• Power Supply: External Power Adapter (Included)
• Operating Temperature: 0°C to 40°C
• Storage Temperature: -40°C to 70°C
• Humidity: 10% to 90% (Non-condensing)
• Certifications: CE, FCC, RoHS

Additional Information:

• Switching Capacity: 2 Gbps
• Packet Forwarding Rate: 1.488 Mpps
• MAC Address Table Size: 8,000 entries
• Jumbo Frame Support: Up to 2048 bytes
