SPECIFICATION

• 5 Gigabit Ports: Provides five 10/100/1000 Mbps Gigabit Ethernet ports for connecting high-bandwidth devices.
• Auto-Negotiation: Automatically detects the optimal speed and duplex mode for each connected device.
• Auto MDI/MDIX: Eliminates the need for crossover cables.
• Plug-and-Play Installation: Easy setup with no configuration required.
• Fanless Design: Ensures quiet and reliable operation.
• Energy Efficient: Incorporates energy-saving features to reduce power consumption.

Technical Specifications:

• Ports: 5 x 10/100/1000 Mbps Auto-Negotiation RJ-45 ports
• Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
• Data Transfer Rates: 10 Mbps, 100 Mbps, 1000 Mbps (Auto-Negotiation)
• Media: UTP Cat. 5e or better
• Flow Control: Backpressure
• Dimensions: 91 x 73 x 22 mm (Approx.)
• Weight: 80g (Approx.)
• Power Supply: External Power Adapter (Included)
• Operating Temperature: 0°C to 40°C
• Storage Temperature: -40°C to 70°C
• Humidity: 10% to 90% (Non-condensing)
• Certifications: CE, FCC, RoHS

Additional Information:

• Switching Capacity: 10 Gbps
• Packet Forwarding Rate: 7.44 Mpps
• MAC Address Table Size: 4000 entries
• Jumbo Frame Support: Up to 9720 bytes
