Features:

2MP high quality image

TVI/AHD/CVI/CVBS

Supports white light illumination, 24/7 color images

Supports 180° horizontal flip, 180° vertical flip

OSD configuration menu, easy to operate

IP67 waterproof and dustproof design, high reliability

OSD configuration menu in 11 languages

3-Axis

Specifications:

Range Uniview

Image sensor 1/3” Progressive Scan CMOS

Maximum resolution 2MP

Main Stream rate 1080p (1920x1080)

Extra Stream rate 720p (1280x720)

Lens 2.8 mm

Viewing Angle (FOV) 100.9° (H), 56.5° (V), 121.8° (D)

Minimum illumination 0.02 Lux (Colour)

Infrared range 20 m

White Light Yes

Image improvements BLC, HLC, DWDR, DAY/NIGHT MODE, 2D. DWDR. SMART IR

Day / Night Color images 24/7

Invert image (Flip) Supports horizontal rotation of 180º and vertical rotation of 180º

Power DC 12V / 2.04W

Surge protection 4KV

Video output BNC, supports HDTVI, HDCVI, AHD and CVBS

Temp. operation -30º C ~ 60º C

Degree of protection Weatherproof IP67

Material Plastic

Dimensions 118mm (Φ) * 96mm (H)

Weight 205 g
