SPECIFICATION

• High-Speed Connectivity: Supports Gigabit Ethernet speeds over single-mode fiber.
• Long Reach: Enables connections up to 10 kilometers.
• Single-Mode Fiber: Optimized for long-distance transmissions.
• Hot-Pluggable: Allows for easy installation and removal without powering down the equipment.
• Compact Design: Small form factor for easy integration into various devices.
• Durability: Metal housing for enhanced EMI protection and durability.
• Reliability: Backed by a 2-year warranty and free technical support.

Technical Specifications:

• Interface: 1000Base-LX (IEEE 802.3z standard)
• Connector: Duplex LC connector
• Fiber Type: 9µm single-mode fiber
• Wavelength: 1310 nm
• Maximum Distance: 10 km
• Data Rate: Up to 1.25 Gbps
• Power Supply: 3.3V
• Power Budget: 10.5 dB
• Operating Temperature: 0 to 70°C
• Storage Temperature: -40 to 85°C
• Dimensions: 56.4 x 13.4 x 10.35 mm (L x W x H)
• Weight: Approximately 8 grams

Additional Features:

• Full Duplex Operation: Supports simultaneous data transmission and reception.
• 802.3x Flow Control: Ensures reliable data transfer.
• Digital Diagnostics Monitoring (DDM): Provides real-time monitoring of key parameters.
• Class 1 Laser Product: Compliant with safety standards.

Applications:

• Data Center Networking: Connecting servers, switches, and storage devices.
• Campus Networks: Extending network connectivity across large distances.
• Metro Ethernet: Providing high-speed connectivity for businesses and service providers.
